Advantages of Bluesun
Products Description
PERC Cell
The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.
The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.
|
Module Type
|
BSM405G12-54HPH
|
BSM410G12-54HPH
|
BSM415G12-54HPH
|
BSM420G12-54HPH
|
BSM425G12-54HPH
|
|||||
|
STC
|
STC
|
STC
|
STC
|
STC
|
||||||
|
Maximum Power (Pmax/W)
|
405
|
410
|
415
|
420
|
425
|
|||||
|
Operating Voltage (Vmpp/V)
|
37.25
|
31.43
|
31.64
|
31.83
|
32.03
|
|||||
|
Operating Current(Impp/A)
|
13.86
|
13.05
|
13.13
|
13.21
|
13.29
|
|||||
|
Open-Circuit Voltage (Voc/V)
|
31.24
|
37.50
|
37.75
|
38.00
|
38.25
|
|||||
|
Short-Circuit Current (Isc/A)
|
12.97
|
13.94
|
14.02
|
14.10
|
14.18
|
|||||
|
Module Efficiency (%)
|
20.7
|
21
|
21.3
|
21.5
|
21.7
|
|||||
|
STC: Irradiance 1000W/㎡,Cell Temperature 25℃, Air Mass AM1.5
|
||||||||||
Packing
Packing Details:36pcs/carton, 936pcs/40hq
